How to integrate APM into NestJS project

In this article, we'll explore how to integrate APM into NestJS projects, empowering developers to monitor, analyze, and enhance the performance of our applications effectively.

Prerequisites

For local development, you can use the docker-compose sample below to init a APM server

// docker-compose.yml
version: '2.0'
services:
  apm-server:
    image: docker.elastic.co/apm/apm-server:7.17.3
    depends_on:
      elasticsearch:
        condition: service_healthy
      kibana:
        condition: service_healthy
    cap_add: ['CHOWN', 'DAC_OVERRIDE', 'SETGID', 'SETUID']
    cap_drop: ['ALL']
    ports:
      - 8200:8200
    command: >
      apm-server -e
        -E apm-server.rum.enabled=true
        -E setup.kibana.host=kibana:5601
        -E setup.template.settings.index.number_of_replicas=0
        -E apm-server.kibana.enabled=true
        -E apm-server.kibana.host=kibana:5601
        -E output.elasticsearch.hosts=["elasticsearch:9200"]
    healthcheck:
      interval: 10s
      retries: 12
      test: curl --write-out 'HTTP %{http_code}' --fail --silent --output /dev/null http://localhost:8200/

  elasticsearch:
    image: docker.elastic.co/elasticsearch/elasticsearch:7.17.3
    environment:
      - bootstrap.memory_lock=true
      - cluster.name=docker-cluster
      - cluster.routing.allocation.disk.threshold_enabled=false
      - discovery.type=single-node
      - ES_JAVA_OPTS=-Xms512m -Xmx512m
    ulimits:
      memlock:
        hard: -1
        soft: -1
    volumes:
      - es-data:/usr/share/elasticsearch/data
    ports:
      - 9200:9200
    healthcheck:
      interval: 20s
      retries: 10
      test: curl -s http://localhost:9200/_cluster/health | grep -vq '"status":"red"'

  kibana:
    image: docker.elastic.co/kibana/kibana:7.17.3
    depends_on:
      elasticsearch:
        condition: service_healthy
    environment:
      ELASTICSEARCH_URL: http://elasticsearch:9200
      ELASTICSEARCH_HOSTS: http://elasticsearch:9200
    ports:
      - 5601:5601
    healthcheck:
      interval: 10s
      retries: 20
      test: curl --write-out 'HTTP %{http_code}' --fail --silent --output /dev/null http://localhost:5601/api/status

volumes:
  es-data:

// docker-compose.yml
version: '2.0'
services:
  apm-server:
    image: docker.elastic.co/apm/apm-server:7.17.3
    depends_on:
      elasticsearch:
        condition: service_healthy
      kibana:
        condition: service_healthy
    cap_add: ['CHOWN', 'DAC_OVERRIDE', 'SETGID', 'SETUID']
    cap_drop: ['ALL']
    ports:
      - 8200:8200
    command: >
      apm-server -e
        -E apm-server.rum.enabled=true
        -E setup.kibana.host=kibana:5601
        -E setup.template.settings.index.number_of_replicas=0
        -E apm-server.kibana.enabled=true
        -E apm-server.kibana.host=kibana:5601
        -E output.elasticsearch.hosts=["elasticsearch:9200"]
    healthcheck:
      interval: 10s
      retries: 12
      test: curl --write-out 'HTTP %{http_code}' --fail --silent --output /dev/null http://localhost:8200/

  elasticsearch:
    image: docker.elastic.co/elasticsearch/elasticsearch:7.17.3
    environment:
      - bootstrap.memory_lock=true
      - cluster.name=docker-cluster
      - cluster.routing.allocation.disk.threshold_enabled=false
      - discovery.type=single-node
      - ES_JAVA_OPTS=-Xms512m -Xmx512m
    ulimits:
      memlock:
        hard: -1
        soft: -1
    volumes:
      - es-data:/usr/share/elasticsearch/data
    ports:
      - 9200:9200
    healthcheck:
      interval: 20s
      retries: 10
      test: curl -s http://localhost:9200/_cluster/health | grep -vq '"status":"red"'

  kibana:
    image: docker.elastic.co/kibana/kibana:7.17.3
    depends_on:
      elasticsearch:
        condition: service_healthy
    environment:
      ELASTICSEARCH_URL: http://elasticsearch:9200
      ELASTICSEARCH_HOSTS: http://elasticsearch:9200
    ports:
      - 5601:5601
    healthcheck:
      interval: 10s
      retries: 20
      test: curl --write-out 'HTTP %{http_code}' --fail --silent --output /dev/null http://localhost:5601/api/status

volumes:
  es-data:

Getting Started

Step 1: Install Elastic APM Node.js Agent

Open your terminal and run the following command to install elastic-apm-node into your project

cd your-project
npm install --save elastic-apm-node

cd your-project
npm install --save elastic-apm-node

This is the official Node.js application performance monitoring (APM) agent for the Elastic Observability solution. It is a Node.js package that runs with your Node.js application to automatically capture errors, tracing data, and performance metrics. APM data is sent to your Elastic Observability deployment -- hosted in Elastic's cloud or in your own on-premises deployment -- where you can monitor your application, create alerts, and quick identify root causes of service issues.

Step 2: Create a elastic-apm.ts file to manage apm agent instance

// @src/libs/apm/elastic-apm/elastic-apm.ts
import APM from 'elastic-apm-node'
// Need this import since APM agent will use env variables by default
import 'dotenv/config'

let instance: APM.Agent | undefined

/**
 * Initializes the APM agent with the provided configuration options.
 * If no configuration is provided, the agent is started with default options.
 * Note:
 * - It must be started before require(...) statements for other modules.
 * - The APM agent automatically instruments modules by interposing itself in the import process.
 * - If a given module is imported before the APM agent has started, then it won’t be able to instrument that module.
 * @param {APM.AgentConfigOptions} [config] - The configuration options for the APM agent.
 * @returns {void}
 */
export const initializeAPMAgent = (config?: APM.AgentConfigOptions): void => {
  instance = config ? APM.start(config) : APM.start()
}

/**
 * Retrieves the instance of the APM agent.
 * Throws an error if the agent is not initialized.
 * @returns {APM.Agent} The instance of the APM agent.
 * @throws {Error} Throws an error if the APM agent is not initialized.
 */
export const getInstance = (): APM.Agent => {
  if (!instance) {
    throw new Error('APM Agent is not initialized (run initializeAPMAgent)')
  }

  return instance
}

// @src/libs/apm/elastic-apm/elastic-apm.ts
import APM from 'elastic-apm-node'
// Need this import since APM agent will use env variables by default
import 'dotenv/config'

let instance: APM.Agent | undefined

/**
 * Initializes the APM agent with the provided configuration options.
 * If no configuration is provided, the agent is started with default options.
 * Note:
 * - It must be started before require(...) statements for other modules.
 * - The APM agent automatically instruments modules by interposing itself in the import process.
 * - If a given module is imported before the APM agent has started, then it won’t be able to instrument that module.
 * @param {APM.AgentConfigOptions} [config] - The configuration options for the APM agent.
 * @returns {void}
 */
export const initializeAPMAgent = (config?: APM.AgentConfigOptions): void => {
  instance = config ? APM.start(config) : APM.start()
}

/**
 * Retrieves the instance of the APM agent.
 * Throws an error if the agent is not initialized.
 * @returns {APM.Agent} The instance of the APM agent.
 * @throws {Error} Throws an error if the APM agent is not initialized.
 */
export const getInstance = (): APM.Agent => {
  if (!instance) {
    throw new Error('APM Agent is not initialized (run initializeAPMAgent)')
  }

  return instance
}

Step 3: Start apm agent in app.ts file

Starting the APM agent early in the application's lifecycle ensures that it can properly instrument all relevant parts of the application code, including HTTP requests and other modules.

// @src/app.ts
// Please note that the order import is so important,
// APM agent need start before the modules such as http,...
import { initializeAPMAgent } from '@src/libs/apm/elastic-apm'
initializeAPMAgent({
  serviceName: 'internal-app-server'
})

async function bootstrap() {
  // ...
}

bootstrap()

// @src/app.ts
// Please note that the order import is so important,
// APM agent need start before the modules such as http,...
import { initializeAPMAgent } from '@src/libs/apm/elastic-apm'
initializeAPMAgent({
  serviceName: 'internal-app-server'
})

async function bootstrap() {
  // ...
}

bootstrap()

Step 4: Capture the error and send to APM server

Create an error interceptor

// @src/libs/apm/elastic-apm/elastic-apm.interceptor.ts
import { CallHandler, ExecutionContext, Injectable, NestInterceptor } from '@nestjs/common'
import { Observable, throwError } from 'rxjs'
import { catchError } from 'rxjs/operators'

import { getInstance } from './elastic-apm'

@Injectable()
export class ElasticApmErrorInterceptor implements NestInterceptor {
  /**
   * Intercepts the execution context and handles errors by capturing them with APM Agent.
   * @param context The execution context.
   * @param next The call handler.
   * @returns An observable that emits the result or throws an error.
   */
  public intercept(context: ExecutionContext, next: CallHandler<any>): Observable<any> {
    return next.handle().pipe(
      catchError(error => {
        getInstance().captureError(error)
        return throwError(() => error)
      })
    )
  }
}

// @src/libs/apm/elastic-apm/elastic-apm.interceptor.ts
import { CallHandler, ExecutionContext, Injectable, NestInterceptor } from '@nestjs/common'
import { Observable, throwError } from 'rxjs'
import { catchError } from 'rxjs/operators'

import { getInstance } from './elastic-apm'

@Injectable()
export class ElasticApmErrorInterceptor implements NestInterceptor {
  /**
   * Intercepts the execution context and handles errors by capturing them with APM Agent.
   * @param context The execution context.
   * @param next The call handler.
   * @returns An observable that emits the result or throws an error.
   */
  public intercept(context: ExecutionContext, next: CallHandler<any>): Observable<any> {
    return next.handle().pipe(
      catchError(error => {
        getInstance().captureError(error)
        return throwError(() => error)
      })
    )
  }
}

Use this interceptor as global scope, there are many ways to do that, One way I suggest you is that you can register a global interceptor directly from the app module definition

// @src/app.module.ts
import { Module } from '@nestjs/common'
import { APP_INTERCEPTOR } from '@nestjs/core'

import { ElasticApmErrorInterceptor } from '@src/libs/apm/elastic-apm.interceptor'

@Module({
  providers: [
    {
      provide: APP_INTERCEPTOR,
      useClass: ElasticApmErrorInterceptor
    }
  ],
  imports: [
    // other modules
  ]
})
export class ApplicationModule {}

// @src/app.module.ts
import { Module } from '@nestjs/common'
import { APP_INTERCEPTOR } from '@nestjs/core'

import { ElasticApmErrorInterceptor } from '@src/libs/apm/elastic-apm.interceptor'

@Module({
  providers: [
    {
      provide: APP_INTERCEPTOR,
      useClass: ElasticApmErrorInterceptor
    }
  ],
  imports: [
    // other modules
  ]
})
export class ApplicationModule {}

Step 5: Add APM environment variables

These env variables is basic config (see more: https://www.elastic.co/guide/en/apm/agent/nodejs/current/configuration.html)

ELASTIC_APM_ACTIVE=true
ELASTIC_APM_SERVER_URL=

ELASTIC_APM_ACTIVE=true
ELASTIC_APM_SERVER_URL=

If the APM server has configured for the secret token or api key, you muse add them into the env variables

ELASTIC_APM_SECRET_TOKEN=
ELASTIC_APM_API_KEY=

ELASTIC_APM_SECRET_TOKEN=
ELASTIC_APM_API_KEY=

Customize the apm agent config

For the ELASTIC_APM_SERVICE_NAME, it can be override by set the env

ELASTIC_APM_SERVICE_NAME=override-name

ELASTIC_APM_SERVICE_NAME=override-name

For the ELASTIC_APM_DISABLE_INSTRUMENTATIONS,it can be override by update the env ELASTIC_APM_DISABLE_INSTRUMENTATIONS (see more: https://www.elastic.co/guide/en/apm/agent/nodejs/current/configuration.html#disable-instrumentations)

ELASTIC_APM_DISABLE_INSTRUMENTATIONS=kafkajs,graphql

ELASTIC_APM_DISABLE_INSTRUMENTATIONS=kafkajs,graphql

Conclusion

With these steps, you've successfully integrated apm agent into your NestJS project. This feature enhances your Node server by automatically capture errors, tracing data, and performance metrics.

For further information, refer to the official documentation on APM Node.js Agent.
